CONNECTION S
Power, Audio and Video Output Connections
Before connecting the power source, ensure that all the connections are properly done.
Connecting to a wall outlet•
Outputting audio and video signal from the main unit to the monitor by the DC car cord.•
DC 9V IN
DC 9V IN
DC 9V OUT
AUDIO/VIDEO
JACK
AUDIO/VIDEO
JACK
AC/DC adaptor for main unit:
This AC/DC adaptor should be used
with 100-240V~50/60Hz 0.6A MAX
AC wall outlets.
DC Out: 9V
DC Current: 1.5A
To wall outlet
(100-240V 50/60Hz)
Monitor
Main Unit
