OnCell G3111/G3151/G3211/G3251 Series User’s Manual Using the Web Console
6-4
2. In either case, the window below should appear, showing the list of sites that you have
configured Internet Explorer to trust. Add the IP address of your OnCell
G3111/G3151/G3211/G3251 here (the factory default IP address is 192.168.127.254).
After adding the OnCell G3111/G3151/G3211/G3251’s IP address as a trusted site, you should
be able to view the web console by entering the OnCell G3111/G3151/G3211/G3251’s IP
address in your browser’s address bar.
Opening the Web Console
Open your web browser and enter 192.168.127.254 in the website address line. This is the default IP
address for the OnCell G3111/G3151/G3211/G3251—if a new address has been assigned, enter the
new address instead. Press ENTER to load the page.
ATTENTION
The examples and figures in this chapter use the OnCell G3111/G3151/G3211/G3251 factory
default IP address of 192.168.127.254. If you have assigned a different IP address to your OnCell
G3111/G3151/G3211/G3251, be sure to adjust accordingly when following these directions.
Please refer to Chapter 3, Initial IP Address Configuration, for details on how to configure the IP
address.
Enter the console password if prompted. (This will not apply if you did not enable password
protection for your OnCell G3111/G3151/G3211/G3251.) The password will be transmitted with
MD5 encryption over the Internet.
