OnCell G3111/G3151/G3211/G3251 Series User’s Manual Initial IP Address Configuration
3-3
ATTENTION
In order to use the ARP setup method, both your computer and the OnCell
G3111/G3151/G3211/G3251 must be connected to the same LAN. You may use a Ethernet cable
to connect the OnCell G3111/G3151/G3211/G3251 directly to your computers Ethernet card.
Before executing the ARP command, your OnCell G3111/G3151/G3211/G3251 must be
configured with the factory default IP address (192.168.127.254) and your computer and the
OnCell G3111/G3151/G3211/G3251 must be on the same subnet.
To use ARP to configure the IP address, complete the following:
1. Obtain a valid IP address for your OnCell G3111/G3151/G3211/G3251 from your network
administrator.
2. Obtain your OnCell G3111/G3151/G3211/G3251s MAC address from the label on the bottom
panel.
3. Execute the arp -s command from your computers MS-DOS prompt as follows:
arp -s <IP address> <MAC address>
For example,
C:\> arp -s 192.168.200.100 00-90-E8-04-00-11
4. Next, execute a special Telnet command by entering the following exactly:
telnet 192.168.200.100 6000
When you enter this command, a Connect failed message will appear, as shown below.
5. After the OnCell G3111/G3151/G3211/G3251 reboots, its IP address will be assigned to the
new address and you can reconnect using Telnet to verify that the update was successful.
Telnet Console
Depending on how your computer and network are configured, you may find it convenient to use
network access to set up your OnCell G3111/G3151/G3211/G3251s IP address. This can be done
using Telnet.
