OnCell G3111/G3151/G3211/G3251 Series User’s Manual Auto IP Report Protocol
E-2
ID List
ID Va lue Description Length Note
1
Server Name
Variable
ASCII char
2
Device ID
2
Little-endian
3
MAC Address
6
6 bytes MAC address. If the MAC
address is "00-90-E8-01-02-03", the
MAC[0] is 0, MAC[1] is 0x90(hex),
MAC[2] is 0xE8(hex), and so on.
4 Serial Number 4, DWORD Little-endian
5
IP Address
4, DWORD
Little-endian (LAN IP)
9
AP ID
4, DWORD
Little-endian
10
IP Address2
4, DWORD
Little-endian (WAN IP)
11
Signal Level
1
Unsiqned char
12
RSSI
1
Unsiqned char
AP ID & Device ID Mapping Table
AP ID
Hardware ID
Product
0x80003700
0x3111
OnCell G3111
0x80003700
0x3151
OnCell G3151
0x80003700
0x3211
OnCell G3211
0x80003700
0x3251
OnCell G3251
