User Manual
Table Of Contents
- OnCell 3120-LTE-1 Quick Installation Guide
- Overview
- Package Checklist
- Installation and Configuration
- Panel Layout of the OnCell 3120-LTE-1
- Device Dimensions
- DIN-rail Mounting
- Wall Mounting (optional)
- Wiring Requirements
- Grounding the Moxa OnCell 3120-LTE-1
- SIM Card Socket
- Connecting the Power Input
- Communication Connections
- LED Indicators
- Specifications
- ATEX / IECEx Zone 2 Certification Information
- Grounding-wire Size

- 12 -
ATTENTION
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
ATTENTIO
N
Do not locate the antenna near overhead power lines or other
electric light or power circuits, or where it can come into
contact with such circuits. When installing the antenna, take
extreme care not to come into contact with such circuits,
because they
may cause serious injury or death
when there is a
surge
. For instructions on proper installation and grounding of
the antenna, refer to national and local codes (for example,
U.S.:
NFPA 70, National Electrical Code, Article 810, and
Canada: Canadian Electrical Code, Section 54).
ATTENTION
For EXPLOSION
-PROOF applications, the OnCell 3120-LTE-1 is
designed and certified to meet ATEX and IECEx
requirements.
You should mount the device in a suitable enclosure rated at
least IP54
, in accordance with IEC/EN 60079-15 standard, so
that it is accessible only by the use of a tool. The device is not
intended for use in an area
with pollution degree rating > 2 in
accordance with EN 60664
-1.
When
you install the OnCell 3120-LTE-1 in an enclosure, the
antennas must
also be installed in such a way that they are
inside the
enclosure. External antenna deployment is allowed
only if the antennas are certified
for ATEX Zone 2 use or
conform to the IECEx standards.
WARNING
EXPLOSION HAZARD!
Do not disconnect equipment unless you have
removed the
power source to the equipment or the area is known to be non
-
hazardous.
