MGate 5102-PBM-PN Quick Installation Guide Version 3.1, November 2019 Technical Support Contact Information www.moxa.
Overview The MGate 5102-PBM-PN is an industrial Ethernet gateway for PROFIBUS-to-PROFINET network communication. Package Checklist Before installing the MGate 5102-PBM-PN, verify that the package contains the following items: • • • • 1 MGate 5102-PBM-PN gateway RJ45 to DB9 cable (for console use) Quick installation guide (printed) Warranty card Please notify your sales representative if any of the above items are missing or damaged.
LED Color Function Steady on: PROFIBUS master is in OPERATE mode Blinking: PROFIBUS master is in CLEAR mode PBM Red PROFIBUS master is in STOP mode Off PROFIBUS master is offline Steady on: PROFINET I/O is connected and controller is in RUN mode Green PN Blinking: PROFINET I/O is connected but controller is in STOP mode Off No connection with I/O Controller Steady: 10 Mbps, no data is transmitting Amber Blinking: 10 Mbps, data is transmitting Ethernet Steady: 100 Mbps, no data is transmitting Green Blinkin
Wall or Cabinet Mounting Two metal plates are provided for mounting the unit on a wall or inside a cabinet. Attach the plates to the unit’s rear panel with screws. With the plates attached, use screws to mount the unit on a wall. The heads of the screws should be 5 to7 mm in diameter, the shafts should be 3 to 4 mm in diameter, and the length of the screws should be more than 10.5 mm. For each screw, the head should be 6 mm or less in diameter, and the shaft should be 3.5 mm or less in diameter.
Power Input and Relay Output Pinouts V2+ Shielded Ground V2- DC DC Power Power Input 2 Input 2 V1+ N.O. Common N.C. V1- DC DC Power Power Input 1 Input 1 Specifications Power Input Power Consumption (Input Rating) Operating Temperature Storage Temperature 12 to 48 VDC 12 to 48 VDC, 430 mA (max.) Standard Models: 0 to 60°C (32 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) -40 to 85°C (-40 to 185°F) ATEX and IECEx Information 1. 2. 3. 4. 5.
ATTENTION For installations in hazardous locations (Class 1, Division 2): These devices are to be installed in an enclosure with a tool-removable cover or door, suitable for the environment. NOTE This equipment is suitable for use in Class 1, Division 2, Groups A, B, C, D, or nonhazardous locations only. WARNING EXPLOSION HAZARD Do not disconnect equipment unless the power has been switched off, or the area is known to be nonhazardous.
