ICF-1150 Series Quick Installation Guide First Edition, November 2008 © 2008 Moxa Inc. All rights reserved. Reproduction without permission is prohibited. Fl.4, No.135, Lane 235, Pao-Chiao Rd. Shing Tien City, Taipei, Taiwan, R.O.C.
Overview Introduction The ICF-1150 series fiber converters are equipped with a multiple interface circuit that can handle RS-232 and RS-422/485 serial interfaces, as well as multi-mode or single-mode fiber. The ICF-1150 series converters are used to extend serial transmission distance up to 5 km (ICF-1150-M, with multi-mode fiber) or up to 40 km (ICF-1150-S, with single-mode fiber).
Rotary Switch for Pull High/Low Resistor Setting Since the RS-485 port can support multi-drop connection or daisy-chain connection, system engineers can connect meters, RTUs, readers, or many other devices together on the same bus. The impedance of the data line will rise according to the number of serial devices on the same bus. To get the system working, the ICF-1150 has a setting for tuning the pull high/low resistor.
Features y “Ring” or “Point to Point” transmission y Extend RS-232/422/485 transmission distance: ¾ up to 40 km with single-mode—ICF-1150-S series ¾ up to 5 km with multi-mode—ICF-1150-M series y Support baudrate up to 921.
ICF-1150-ST 8.8 48.39 115 33.41 13.66 70 8.8 30.3 Top View Front View Rotary Switch for Pull High/Low Resistor OP Mode Switch Fiber Port RS-422/485 ATTENTION LED Electrostatic Discharge Warning! To protect the product from damage due to electrostatic discharge, we recommend wearing a grounding device when handling your ICF-1150 series.
Mounting The aluminum DIN-Rail attachment plate should be fixed to the back panel of the ICF-1150 when you take it out of the box. If you need to reattach the DIN-Rail attachment plate to the ICF-1150, make sure the stiff metal spring is situated towards the top, as shown in the figures below. STEP 1: Insert the top of the DIN-Rail into the slot just below the stiff metal spring. STEP 2: The DIN-Rail attachment unit will snap into place as shown below.
Fiber Cable SC-Port Pinouts SC-Port to SC-Port Cable Wiring A A B B Rx Cable Wiring A B Tx ST-Port Pinouts Rx A B ST-Port to ST-Port Cable Wiring A A B B Cable Wiring A B Tx A B ATTENTION This is a Class 1 laser/LED product. Do not stare into the laser beam. Switch Settings There are 4-DIP switches on the front panel of the ICF-1150.
ATTENTION For Fiber Ring Users: If the Rx LEDs of the converter glow continuously, remove the fiber cable and connect again, then the system will not have the same condition. NOTE: “Ring Mode” can only be used for half-duplex applications. LED Indicators There are 3 LEDs on the front panel of the ICF-1150.
ICF-1150I- S/M-SC/ST: 163 mA @ 12V Mechanical Dimensions (W × D × H) Material Gross Weight Regulatory Approvals CE FCC TÜV EMI EMS 30.
