User`s manual
Table Of Contents

A-4 Intellio C320Turbo/PCI
Basic Module ( Front View )
Multiport Controller
B?a?s?i?c M?o?d?u?l?e
Power TxD RxD DTR DSR RTS CTS DCD Module Channel
Basic Module ( Rear View )
P9
P1
P16
P8
To next module
From PC
DC IN ON/OFF
To Control Board
Extensive Module (for Rackmount option)
❖ 8 or 16 RS-232 serial ports
❖ 16550C UART chip with 32 bytes FIFO (Tx+Rx) and on-chip hardware flow
control
❖ Each UART chip drives one serial port (Max. 460.8 Kbps)
❖ Full modem control (RS-232 interface)
❖ RJ-45 connector for each serial port
Extensive Module ( Front View)
Multiport Controlle r
E‧x‧ t‧e ‧n‧s‧i‧v‧e M‧o‧d‧ u‧l‧e
Power
P9
P1
P16
P8
To next module
From previous module
