Connection Option and Cable Wiring
Intellio C320Turbo/PCI User's Manual 5-15
10-signal-pin Link Cable (for long range extension only)
If the external power adapter is applied to the CPU/Basic Module, you will need to
use the 10-pin cable accompanying with the Long Range Extension Kit. The Control
Board to CPU/Basic Module should have only 10 signal pins with the following
pinouts.
Warning! Make the link cable carefully and precisely according to the
following pinout, otherwise you will risk damaging the Control
Board and CPU/Basic Module.
Pin No. Signal Pin No. Signal
2 DX+ 14 CLK-
3DR+ 15FSX+
11 CLK+ 16 FSR+
12 FSR- 24 FSX-
13 DX- 25 DR-
☞ You can connect the existing 10-signal-pin cable to a 25-signal-pin cable
to form a longer 2-segment cable to extend the connection distance up to
100 meters (328 ft).
