3-28 Intellio C320Turbo/PCI User's Manual
Taking 8 port Intellio C320Turbo/PCI as an example,
Administration Utility - mxadm
You can use the administration utility, mxadm, to change the Intellio
C320Turbo/PCI basic and advanced configuration, to reset the board, to tune
performance and to remove the installed MOXA driver from the UNIX system,
which are detailed as follows. For the details of the rest utilities: port monitoring,
and terminal emulator, please refer to “UNIX” section of “Serial Programming
Tools” chapter.
Basic Configuration
This utility is to configure basic settings for the driver.
1. In the “Basic Configuration” dialog box, you should first press Enter in the
2
3
4
5
6
7
8
1
To Control Board
CPU Module
UART Module
/dev/ttya12
/dev/ttya13
/dev/ttya14
/dev/ttya15
/dev/ttya17
/dev/ttya16
/dev/ttya11
/dev/ttya18
I 8
