MOXA TTY Device Naming Convention
If the Intellio C320Turbo/PCI is successfully configured, there will be two tty
devices created for each port at /dev directory: one is non-MODEM tty (e.g.
ttya11), and the other is MODEM tty (e.g. ttyA11). The two devices are actually
accessing the same physical port except that the MODEM tty has to check the ON
status of DCD signal to be able to open device, and closing device automatically as
DCD signal is OFF.
The convention of the MOXA tty device name is /dev/tty{a-d}{1-4}{1-8}, where (if
continuous 8 ports are viewed as an 8-port unit for Intellio C320Turbo/PCI
Rackmount):
"tty" + "A" + "B" + "C"
Port ordinal number in a UART Module/8-port unit,1-8
UART Module/8-port unit ordinal number,1-4
Board ordinal number
"a"or "A": 1st MOXA board
"b"or "B": 2nd MOXA board
"c"or "C": 3rd MOXA board
"d"or "D": 4th MOXA board
Capitals indicate a MODEM port
Standard tty device prefix
/dev/ttya18
/dev/ttya17
/dev/ttya16
/dev/ttya15
/dev/ttya14
/dev/ttya13
/dev/ttya12
/dev/ttya11
P1 P8
To next module
From PC
DC IN ON/OFF
Basic Module
