Software Installation
Intellio C320Turbo/PCI User's Manual 3-25
1. /dev/fd0135ds18 (A: 1.44MB)
2. /dev/fd096ds15 (A: 1.2 MB)
3. /dev/fd1135ds18 (B: 1.44MB)
4. /dev/fd196ds15 (B: 1.2 MB)
5. Hard Disk /tmp/moxa
Select:
Step 6. The MOXA Multiport Board Installation Utility dialog will show for
driver installation. When finished, press any key to continue.
SCO UNIX or SCO OpenServer or XENIX
You will be prompted to rebuild kernel at this moment and you are
recommended to do so unless you need to install other driver. Please
type “y”. After kernel rebuild, please shutdown the system on your
own.
UNIX SVR4.2 or UnixWare or MITUX
You will be prompted to shutdown the system on your own for
kernel rebuilding and you are recommended to do so.
Step 7. Once the system reboots, run “mxadm” to configure the board and port.
Select and open “Basic Configuration” to do the basic board and port
configuration. You may further optionally select and open “Advanced
Configuration” to do the advanced settings.
Select and open “Board Reset” to reset the driver and board for the latest
configuration to take effect.
For more details, see later section, “Administration Utility - mxadm”.
☞ Up to now, you have already completed the whole installation and the
Intellio C320Turbo/PCI board is ready to work.
Note! Please double check if all the Intellio C320Turbo/PCI
components: Control Board, link cable and external modules
are connected and fastened tightly to make sure that the system
and the driver starts successfully.
Please type 1, 2, 3, 4 or 5.
