3-6 Intellio C320Turbo/PCI User's Manual
Classical Mode: It lets MOXA ports behave like generic COM ports.
Transmission for small data packets would be more precisely and reliable.
8. Click [OK] in the “Individual Port Setting” and the “Property” dialog boxes to
go back to the “MOXA Configuration Panel” dialog box. Click [OK] to finish
the configuration.
However, if you installed more than one board, click [Add] and repeat steps 6
and 7 to configure another board. Up to four Intellio C320Turbo/PCI boards
can be installed in a system.
9. When the configuration is done, click [OK] in the “Network” dialog box.
10. Restart Windows NT system. The latest configuration will not take effect
unless the system restarts.
Note ! Please double check if all the Intellio C320Turbo/PCI
components: Control Board, link cable and external
cable/module, are connected and fastened tightly to make sure
that the system and the driver start successfully later.
