Software Installation
Intellio C320Turbo/PCI User's Manual 3-5
Note ! You may skip the following settings and go directly to the next step 8
if you do not require any particular performance tuning for the
In the “Advanced Settings” dialog, you may customize the driver with the
following two features:
D UART FIFO
Enable: You can set this feature to “Enable” (default) and gain best performance
for the board.
Disable: You can set this feature to “Disable” to avoid from data loss when
communicating with communication devices using S/W flow control.
D Transmission Mode
Hi-Performance Mode: This feature is set to “Hi-Performance” by default,
which accelerates the reaction of data writing behavior by utilizing buffering
technology. It lets your communication software reach maximum data throughput
in large data transmission.
