2 Hardware Installation
Hardware InstallationHardware Installation
Hardware Installation
The installation of Intellio C320Turbo/PCI consists of hardware installation and
software installation. For software installation, please refer to the respective section
of operating systems in the next chapter. Hardware installation is stated in this
chapter. The no-switch-no-jumper Intellio C320Turbo/PCI board’s hardware
configuration for IRQ and memory addresses is automatically assigned by PCI
BIOS. Hence, it is a must to have the board plugged first before installing
software driver. After this, simply install the Control Board into the PC and then
connect one of the connection options, Desktop or Rackmount.
The Intellio C320Turbo/PCI hardware installation consists of Control Board
installation and external module installation. Make sure you have connected the
Control Board with proper number of external modules .
Installing the Intellio C320Turbo/PCI Control Board
Step 1: Power off the PC.
Warning ! Make sure you switch off the system before installing
any PCI board.If you don’t, you may risk damaging your
system and the board.
Step 2: Remove the PC’s cover.
Step 3: Remove the slot cover bracket if present.
Step 4: Plug the Intellio C320Turbo/PCI firmly into any free 32-bit PCI slot.
Step 5: Fasten the holding screw to make the Control Board fixed.
