Embedded Computers for Automation >
IA260 Series
Dimensions
Package Checklist
IA260 or IA260-T computer•
Wall mounting kit•
DIN-Rail mounting kit•
Ethernet cable: RJ45 to RJ45 •
cross-over cable, 100 cm
CBL-RJ45F9-150: 8-pin RJ45 to DB9 •
female console port cable, 150 cm
CBL-RJ45M9-150: 8-pin RJ45 to DB9 •
male serial port cable, 150 cm
Universal Power Adaptor•
Document and Software CD•
Quick Installation Guide (printed)•
Warranty Card•
Ordering Information
Software Specifi cations
112.6 mm
162 mm
52 mm
Linux
Kernel Version: 2.6.23
Protocol Stack: ARP, PPP, CHAP, PAP, IPv4, ICMP, TCP, UDP,
DHCP, FTP, SNMP V1, HTTP, NTP, NFS, SMTP, SSH 1.0/2.0, SSL,
Telnet, PPPoE, OpenVPN
File System: JFFS2, NFS, Ext2, Ext3, VFAT/FAT
System Utilities: bash, tinylogin, telnet, ftp, smtpclient, scp
telnetd: telnet server daemon
sshd: secure shell server
Apache: web server daemon
openvpn: virtual private network
pppd: dial in/out over serial port daeon
snmpd: snmpd agent daeon
inetd: TCP server manager program
openssl: open SSL
Linux Tool Chain:
• GCC (V4.2.1): C/C++ PC Cross Compiler
• GDB (V5.3): Source level debug server
• Glibc (V2.2.5): POSIX standard C library
Windows Embedded CE 6.0
System Utilities: Windows command shell, telnet, ftp,
web-based administration manager
File System: FAT (on-board fl ash)
Protocol Stack: TCP, UDP, IPv4, SNMP V2, ICMP, IGMP, ARP,
HTTP, CHAP, PAP, SSL, DHCP, SNTP, Telnet, FTP, PPP
Telnet Server: Allows remote administration through a standard
telnet client.
FTP Server: Used for transferring fi les to and from remote computer
systems over a network.
Web Server (httpd): Includes ASP, ISAPI Secure Socket Layer
support, SSL 2, SSL 3, Transport Layer Security (TLS/SSL 3.1)
public key-based protocols, and Web Administration ISAPI
Extensions.
Dial-up Networking Service: RAS client API and PPP, supporting
Extensible Authentication Protocol (EAP) and RAS scripting.
Watchdog Server: CPU hardware function for resetting the CPU in a
user-specifi ed time interval; activated by a Moxa library function
Application Development Software:
• Moxa WinCE 6.0 SDK
• C Libraries and Run-times
• Component Services (COM and DCOM)
• Microsoft® .NET Compact Framework 2.0 with SP2
• XML, including DOM, XQL, XPATH, XSLT, SAX
• SOAP Toolkit
• Winsock 2.2
Available Models
IA260-CE: RISC-based embedded computer with 4 serial ports, 8 DIs, 8 DOs, dual LANs, VGA,
CompactFlash, USB, Win CE 6.0 OS, -10 to 60°C operating temperature
IA260-LX: RISC-based industrial embedded computer with 4 serial ports, 8 DIs, 8 DOs, dual LANs,
VGA, CompactFlash, USB, Linux OS, -10 to 60°C operating temperature
IA260-T-CE: RISC-based embedded computer with 4 serial ports, 8 DIs, 8 DOs, dual LANs, VGA,
CompactFlash, USB, Win CE 6.0 OS, -40 to 75°C operating temperature
IA260-T-LX: RISC-based industrial embedded computer with 4 serial ports, 8 DIs, 8 DOs, dual
LANs, VGA, CompactFlash, USB, Linux OS, -40 to 75°C operating temperature
