User`s manual

Hardware Overview
MOXA EtherDevice Server User’s Manual
4-3
LED Indicators
The front panel of MOXA EtherDevice Server contains several LED indicators. The
function of each LED is described in the table below.
LED Color State Description
On
Power is being supplied to power
input P1
P1
AMBER
Off
Power is not being supplied to power
input P1
On
Power is being supplied to power
input P2
P2
AMBER
Off
Power is not being supplied to power
input P2
On
MOXA EtherDevice Server’s self-test
failed or power to one of the power
inputs is cut off.
Fault
RED
Off
MOXA EtherDevice Server’s self-test was
successful
On 10 Mbps link has been established
Blinking Data is being transmitted at 10 Mbps
10/LNK/ACT
GREEN
Off Port’s 10 Mbps link is inactive
On 100 Mbps link has been established
Blinking Data is being transmitted at 100 Mbps
100/LNK/ACT
GREEN
Off Port’s 100 Mbps link is inactive
On 100BaseFX port is active
Blinking Data is being transmitted at 100 Mbps
LNK/ACT
AMBER
Off 100BaseFX port is inactive
