Moxa EtherDevice™ Switch EDS-518A Series Hardware Installation Guide Fifth Edition, June 2010 © 2010 Moxa Inc. All rights reserved. Reproduction without permission is prohibited. Fl.4, No.135, Lane 235, Pao-Chiao Rd. Shing Tien City, Taipei, Taiwan, R.O.C.
Package Checklist Moxa EtherDevice™ Switch is shipped with the following items. If any of these items are missing or damaged, please contact your customer service representative for assistance.
Panel Views of EDS-518A 1 2 4 1. Grounding screw 2. Console port 3. 4. Heat dissipation orifices 6-pin terminal block for DI 1, DI 2, and PWR 2 6-pin terminal block for PWR1 Relay 1, and Relay 2 5. 3 5 6 MSTR/HEAD CPLR/TAIL 7 8 9 6 10 11 6 6. 10/100BaseT(X), ports 1 to 16 7. PWR 1: LED for power input 1 8. PWR 2: LED for power input 2 9. Fault LED 10. MSTR/HEAD LED 11. CPLR/TAIL LED 12. 10/100/1000BaseT(X), port G2 13. 10/100/1000BaseT(X), port G1 14. Turbo Chain Logo 15.
Panel Views of EDS-518A (SC/ST Type) NOTE: The appearance of EDS-518A-SS-SC 1 is identical to EDS-518A-MM-SC. 2 4 The appearance of EDS-518A-MM-ST is identical to EDS-518A-MM-SC. 3 5 6 MSTR/HEAD CPLR/TAIL 6 16 17 7 8 9 21 19 10 11 20 21 1. Grounding screw 2. Console port 3. 4. Heat dissipation orifices 6-pin terminal block for DI 1, DI 2, and PWR 2 6-pin terminal block for PWR1 Relay 1, and Relay 2 5. 6. 10/100BaseT(X), ports 1 to 14 7. PWR 1: LED for power input 1 8.
Mounting Dimensions (unit = mm) 30.00 13.4 9 15.00 36.91 71.01 0.79 TX 13 14 11 12 9 10 16 PWR1 PWR2 DlN-Rail RX FAULT 100M TX 35.00 7 8 5 6 3 4 1000M 1000M 100M G1 1 135.00 100M 2 10M EDS-518A-MM-SC Front View 127.52 Side View 3.5 6 6 18.2 13.9 57.05 13.9 10 10 5 66.80 135.00 RX G2 DlN-Rail Kit MSTR/HEAD CPLR/TAIL 15 7.5 55 7.5 27.20 48.30 135.00 70 46 DlN-Rail Kit 86.80 7.75 30.50 7.
Wall Mounting (Optional) For some applications, you will find it convenient to mount Moxa EDS-518A on the wall, as shown by the following illustrations: STEP 1—Remove the aluminum DIN-Rail attachment plate from the Moxa EDS-518A rear panel, and then attach the wall mount plates with M3 screws, as shown by the figure on the right. Top plate Ö Bottom plate STEP 2—Mounting Moxa EDS-518A on the wall requires 4 6.0 mm screws.
II 3G 1. 2. 3. 4. 5. ATEX Information Certification number DEMKO 09 ATEX 0812123X Ambient range (-40°C ≤ Tamb ≤ 75°C) Certification string (Ex nC IIC T4) Standards covered ( EN60079-0:2006, EN60079-15:2005) The conditions of safe usage: y The Ethernet Communication Devices are to be mounted in an IP54 enclosure and used in an area of not more than pollution degree 2 as defined by IEC60664-1. y A 4mm2 conductor must be used when connection to the external grounding screw is utilized.
You should also pay attention to the following points: y Use separate paths to route wiring for power and devices. If power wiring and device wiring paths must cross, make sure the wires are perpendicular at the intersection point y NOTE: Do not run signal or communications wiring and power wiring through the same wire conduit.
V1- V1+ STEP 1: Insert the negative/positive DC wires into the V-/V+ terminals, respectively. STEP 2: To keep the DC wires from pulling loose, use a small flat-blade screwdriver to tighten the wire-clamp screws on the front of the terminal block connector. STEP 3: Insert the plastic terminal block connector prongs into the terminal block receptor, which is located on the EDS-518A’s top panel.
2. 3. The information to the left of the left vertical dashed lines gives the pinouts of the relevant Moxa EtherDevice Switch port. The information to the right of the right vertical dashed line gives the pinouts of the opposing device’s port. NOTE 1. 2. The pin numbers for male DB9 and DB25 connectors, and hole numbers for female DB9 and DB25 connectors are labeled on the connector. However, the numbers are typically quite small, so you may need to use a magnifying glass to see the numbers clearly.
RJ45 (10-pin) to DB25 (F) Cable Wiring Moxa EtherDevice Server COM Port RJ45 Plug Pin 1 RJ45 Connector Female DB25 Connector Cable Wiring 1 DCD 2 DSR 3 RTS GND 4/7 5 TxD 6 RxD 8 CTS 9 DTR 8 6 4 7 2 3 5 20 DCD DTR CTS GND RxD TxD RTS DSR 10/100BaseT(X) Ethernet Port Connection The 10/100BaseT(X) ports located on Moxa EtherDevice Switch’s front panel are used to connect to Ethernet-enabled devices.
RJ45 (8-pin) to RJ45 (8-pin) Cross-over Cable Wiring Cross-Over Cable Switch Port (NIC Port) RJ45 Plug Pin 1 RJ45 Connector (Rx+) (Rx-) (Tx+) (Tx-) Tx+ TxRx+ Rx- Switch Port (NIC Port) RJ45 Connector Cable Wiring 3 6 1 2 1 2 3 6 Rx+ RxTx+ Tx- (Tx+) (Tx-) (Rx+) (Rx-) 100BaseFx Ethernet Port Connection The concept behind the SC/ST port and cable is quite straightforward. Suppose you are connecting devices I and II.
LED Indicators The front panel of Moxa EDS-518A contains several LED indicators. The function of each LED is described in the following table: LED Color PWR1 AMBER State On PWR2 FAULT Description Power is being supplied to power input P1. Off Power is not being supplied to power input P1. On Power is being supplied to power input P2. Off Power is not being supplied to power input P2. On When the corresponding PORT alarm is enabled, and a user-configured event is triggered.
On 1000M (TP/SFP) TP/SFP port’s 1000 Mbps link is active. GREEN Blinking Data is being transmitted at 1000 Mbps. Off TP/SFP port’s 1000 Mbps link is inactive. Specifications Technology Standards IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100Base FX, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802.3x for Flow Control, IEEE 802.1D for Spanning Tree Protocol, IEEE 802.1w for Rapid STP, IEEE 802.1Q for VLAN Tagging, IEEE 802.1p for Class of Service, IEEE 802.
SX LX LHX ZX Wavelength 850 nm 1310 nm 1310 nm 1310 nm Max. Tx -4 dBm -3 dBm 1 dBm +5 dBm Min. Tx -9.5 dBm -9.5 dBm -4 dBm 0 dBm Rx Sensitivity -18 dBm -20 dBm -24 dBm -24 dBm Link Budget 8.5 dB 10.5 dB 20 dB 24 dB Typical Distance 550m (a) 275m (b) 1100m (c) 550m (d) 10km (e) 40km (e) 80km (f) Saturation 0 dBm -3 dBm -3 dBm -3 dBm a. [50/125 μm, 400 MHz*km] cable b. [62.5/125 μm, 200 MHz*km] cable c. [50/125 μm, 800 MHz*km] cable d. [62.5/125 μm, 500 MHz*km] cable e.
Casing IP30 protection, metal case Dimensions 95 × 135 × 140 mm (W × H × D) Weight 1.63 kg Installation DIN-Rail, Wall Mounting (optional kit) Environment Operating Temperature 0 to 60°C (32 to 140°F), -40 to 75°C (-40 to 167°F) for –T models Storage Temperature -40 to 85°C (-40 to 185°F) Ambient Relative Humidity 5% to 95% (non-condensing) Regulatory Approvals Safety UL60950-1, UL 508 CSA C22.2 No.
