Technical Specifications A - 5
Skew Tolerance +/- 60° from normal
Ambient Light Indoor: 450 ft. candles (4845 lux)
Outdoor: 9000 ft. candles (96,900 lux)
Sunlight: 8000 ft. candles
Fluorescent: 450 ft. candles
Focal Distance From center of exit window: 18.5 cm (7.3 in.)
Aiming Element (VLD) 655 nm +/- 10 nm
Illumination Element (LED) 625 nm +/- 5 nm
Camera Specifications
Resolution 8 Mega pixel
Table A-2
Data Capture Supported Symbologies
Item Description
1D Bar Codes Chinese 2 of 5 Codabar Code 11
Code 128 Code 39 Code 93
Coupon Code Discrete 2 of 5 EAN-8
EAN-13 GS1 DataBar GS1 DataBar 14
GS1 DataBar Expanded GS1 DataBar Expanded Stacked
GS1 DataBar Limited Interleaved 2 of 5 ISBT 128
Korean 2 of 5 Matrix 2 of 5 MSI
TLC39 Trioptic 39 UCC/EAN 128
UPCA UPCE UPCE1
UPC/EAN Supplementals Webcode
2D Bar Codes Australian Postal Aztec Canadian Postal
Composite AB Composite C Data Matrix
Dutch Postal Japanese Postal Linked Aztec
Maxi Code Micro PDF-417 microQR
PDF-417 QR Code US Planet
UK Postal US Postnet USPS 4-state (US4CB)
Table A-1
MC67 Technical Specifications (Continued)
Item Description
