Chapter 2: Introduction to AT Commands
January 31, 2007 AT Commands Reference Manual 2-13
+MIPCONF This command allows to configure TCP stack parameters, such as
retransmissions number, upper and bottom limits of retransmission
timeout, close delay.
Page 3-319
+MIPDATA
This unsolicited event is sent to the terminal indicating a
data comes from Network when G24 is in pseudo-command
mode.
Page 3-317
+MIPODM This command causes the G24 module to initialize a new socket in
Online Data Mode and open a connection with a remote side.
Page 3-308
+MMAD This command reads and monitors digital value from a specified
ADC.
Page 3-184
+MPSU This command defines the functionality of the second physical
UART.
Page 3-176
+MRST This command enables customer software to perform a hard reset
to the G24 unit.
Page 3-172
+MTCTS This command sets the CTS pin of the RS232 to not active (high),
waits one second and then sets the CTS to active (low).
Page 3-163
+MTDTR This command checks and displays the physical current status of
the DTR pin of the RS232.
Page 3-162
+MVC
This AT command is used to choose and configure the
priority order of the supported voice codecs (vocoders).
Page 3-42
+TADIAG This command queries actual ADC values of the antennas.
Page 3-175
+TASW This command controls the antenna switch mechanism.
Page 3-174
+TCLCC This command displays a list of all current G24 calls and their
statuses, and also enables/disables the unsolicited indication of the
call list.
Page 3-48
+TPIN This command queries the number of remaining SIM PIN/PUK
entering attempts
Page 3-218
+TSMSRET This command controls the SMS sending retry.
Page 3-127
+TWUR This command is used to query the wakeup reason(s).
Page 3-174
+TWUS This command is used to set the wakeup reason(s).
Page 3-172
A This command answers an incoming call, placing the G24 into the
appropriate mode, as indicated by the RING message.
Page 3-19
D This command places a voice call on the current network, when
issued from an accessory device.
Page 3-13
E This command defines whether the G24 echoes the characters
received from the user, (whether input characters are echoed to
output).
Page 3-228
F This command is supported for backward compatibility only, and
has no effect.
Page 3-331
H This command hangs up, or terminates a particular call.
Page 3-17
Table 2-1: Core AT Commands (Cont.)
AT Command Description Page
