Chapter 3: AT Commands Reference
January 31, 2007 AT Commands Reference Manual 3-287
The following table shows the +CGPADDR parameters.
Example
AT+CGPADDR=?
+CGPADDR: (1,2,3)
OK
AT+CGPADDR=1
+CGPADDR: 1,0.0.0.0
OK
Table 3-195: +CGPADDR Parameters
<Parameter> Description
<cid> A numeric parameter that specifies a particular PDP context definition. If no <cid>
is specified, the addresses for all defined context are returned.
<PDP_address> A string that identifies the MT in the address space applicable to the PDP. The
address may be static or dynamic. For a static address, it will be the one assigned
during the last PDP context activation that used the context definition referred to by
<cid>. <PDP_address> is omitted if none is available.
