Audio
3-210 AT Commands Reference Manual January 31, 2007
Example
AT+CRTT=6,0 //Ring type number 6, operation 0 (play)
OK //When 6 is in the supported <RingTypeNumber> range
AT+CRTT=6,2 //Ring type number=6, operation 2 (stop)
OK
AT+CRTT=?
+CRTT: (6-45),(0-2)
OK
AT+CRTT?
+CRTT: 6 //Ring type number 6
AT+CRTT=5,4 //Invalid operation
+CME ERROR: <err>
Table 3-145: Ring Tone Types Available
CRTT=X Ring Tone Style Name CRTT=X Ring Tone Style Name
6 Continental 26 Interlude
7 Classic 27 Notify
8 Attention 28 Provincial
9 Siren 29 Random
10 Start Up 30 Snaggle
11 Start Up 31 Standard
12 Alert 32 Alert Tada
13 Bells 33 Triads
14 Bits & Bytes 34 Up and Down
15 Chimes high 35 Wind Chimes
16 Chimes low 36 Latin Loops
17 Chord high 37 Walkin Around
18 Chord low 38 Acoustica
19 Claps 39 Power Surge
20 Cosmic 40 Passion
21 Ding 41 Street Style
22 Door Bell 42 Urban Style
23 Drum 43 Onyx
24 Fanfare 44 Waves
25 Harmonics 45 Clouds
