Audio
3-198 AT Commands Reference Manual January 31, 2007
ATS94=2
+CME ERROR: <err>
ATS94?
000 //Sidetone disabled
OK
S96, Echo Canceling
This command suppresses a large amount of the output sound picked up by the input device
(cancels all echo). S96 value is saved in the Flex.
The following table explains the use of the ATS96 set.
The following table shows the S96 parameters.
Example
ATS96=1 //Enable echo canceling
Table 3-135: ATS96 and ATS94 Behavior
ATS96 ATS94 Echo Cancel Noise Suppress ST
00 Disabled Disabled Disabled
01 Disabled Disabled Enabled
10 Enabled Enabled Disabled
11 Enabled Enabled Disabled
Command Type Syntax Response/Action Remarks
Set
ATS96=<n> OK
or:
+CME ERROR: <err>
The Set command sets the echo
canceling status.
Read
ATS96? <000-disabled,
001-enabled>
OK
or:
+CME ERROR: <err>
The Read command returns the echo
canceling status.
Test
ATS96=? +CME ERROR: <err>
Table 3-136: S96 Parameters
<Parameter> Description
<n> 0 Disable echo canceling. Disable noise suppression
1 Enable echo canceling. Enable noise suppression
