Audio
3-192 AT Commands Reference Manual January 31, 2007
Table 3-129 shows the differences between Basic and Advanced audio modes in controlling the
audio.
Audio Setup
The G24 has two audio modes: 'Basic Audio' and 'Advanced Audio'. Each mode has a different
behavior and a set of relevant AT commands.
Figure 3-2 describes the two audio modes, switching between them and the AT commands related
to each mode.
Figure 3-2: Audio Modes
Table 3-129: Basic and Advanced Audio Modes Comparison
Basic Audio Advanced Audio
Path Paths are set automatically
(upon interrupt).
Paths are set manually. All routings are
available; any microphone with any speaker
for each type of sound (voice, keypad, ring,
etc.).
Gain There are two types of
gains: phone (voice,
keypad) and ring.
There is a matrix of gains: a different gain is
saved for each type of sound through a
specific speaker.
For example, one volume level for rings
through the speaker and a different volume
level for rings through the transducer.
Therefore, there will be 16 different volume
levels, which is the product of the number of
output accessories (speaker, headset speaker,
transducer and digital output) and the
number of audio tones (voice, keypad, ring
and alert).
Algorithm Algorithms are set by
ATS94 and ATS96.
Algorithms are set by AT+MAFEAT.
'Advanced
Audio' specific
Commands:
AT+MAPATH
AT+MAVOL
AT+MAMUT
AT+MAFEAT
'Basic Audio'
specific
Commands:
AT+CRSL
AT+CLVL
AT+CMUT
ATS94
ATS96
Basic Audio Advanced Audio
Audio Common
Commands:
AT+MADIGITAL
AT+VTD
AT+VTS
AT+CRTT
AT+CALM
AT+MMICG
Any use of Advanced
setup specific commands
Power Up
