Technical information

Network
3-152 AT Commands Reference Manual January 31, 2007
Cell ID Cell Identity parameter, from System Info 3.
CellResHys Cell reselect hysteresis, used to compute C2, in Bm (0 to 14 dBm). It is broadcast
on System Info 3.
Cell Resel. Offset Cell Reselect Offset, in dBm (between 0 and 63 dBm). It is broadcast on System
Info 3 rest octets.
Channel type Type of channel used in the current operating mode.
Cipher mode GSM encryption algorithm used. "5x" is displayed for the A5/x algorithm. "00"
means there is no encryption. Hashes ("##") indicate an unknown algorithm.
Coding Scheme CS1 to CS4 for GPRS or modulation and coding scheme MC1 to MC9 for EDGE.
Deliver order Indicates whether the GPRS bearer shall provide in-seq SDU delivery or not.
Downlink coding
scheme from
(Timeslot, coding
scheme)
Coding scheme for the downlink data transmission (between 1 and 4). "*"
indicates an unknown coding scheme.
Downlink timeslot
from (Timeslot,
coding scheme)
Timeslot used for downlink data transfer in the current TBF. Information for as
many as four timeslots can be displayed.
DTX Indicates whether the use of discontinuous transmission has been reported to the
network at least once during the last period of EFEM parameter refresh.
ECSC Indicates whether the network accepts Early Classmark Sending (which it
indicates in System Info 3).
Erroneous SDU
delivered
Indicates whether the GPRS bearer detected as erroneous shall be delivered or
discarded.
GPRS cell indicator Indicates whether the serving cell offers GPRS services.
Granted delay class Delay class (between 1 and 6; 0 or 7 for reserved) granted by the network for the
current PDP context.
Granted mean
throughput
Mean throughput (in decimal, between 0 and 32) granted by the network for the
current PDP context.
Granted peak
throughput
Peak throughput (in decimal, between 0 and 15) granted by the network for the
current PDP context.
Granted reliability
class
Reliability class (between 0 and 7) granted by the network for the current PDP
context.
Granted precedence
class
Precedence class (between 0 and 7) granted by the network for the current PDP
context.
Guaranteed bit rate dl Guaranteed bit rate for Downlink in KPBS.
Guaranteed bit rate ul Guaranteed bit rate for Uplink in KPBS.
HSN Hopping Sequence Number (between 0 and 63).
IP address IP address for the PDP context.
LAC Location Area Code.
MAIO Mobile Allocation Index Offset (between 0 and 63).
Table 3-103: EFEM Parameters (Cont.)
Abbreviation/Term Description
