Specifications

Telit G30 module was designed with regards to electrical, mechanical and software
compatibility to G24-L module. The following is delta within electrical interfaces and
features that has to be considered when using G30.
Not supported features in G30:
 EDGE
 USB
 ADC3
 IGN
New supported features in G30:
 VRTC
 Esim- Embedded SIM
 Unit ready indication using reset signal
 FOTA ATs
 Appzone application: I2C, SPI
Telit G30 current consumption values are different than G24-L. Please refer to the Developer
Guide for power consumption values details.
Telit G30 supports the following interfaces:
 UART
 SPI for logging
 SIM card
 I2C (via Appzone SW package)
