Installation Instructions

No. Descrption

2 Tag

2.7.2

Programming RFID (If Equipped)

Reprogram the tag (up to 12 ASCII characters when encoded to hexadecimal format) by using any

UHF Gen 2 capable RFID writer, for example, Motorola Solutions MC9090-G.

NOTICE: Follow the read direction in RFID Reading on page 74 to optimize reprogramming.

Table 11: Model Number Chart in 12-Digit ASCII Format

Model Number Radio Tier/Band/Output Level Last Two Digits

M22URS9PW1BN APX 4500 700/800 MHZ F8

M24URS9PW1BN APX 2500 700/800 MHZ F8

M25URS9PW1BN APX 6500 700/800 MHZ F5

M25URS9PW1BNI APX 5500 700/800 MHZ F5

M36URS9PW1BN APX 1500 700/800 MHZ F9

Table 12: Serial Number with Radio Band/Tier/Power

Characters Radio Band/Tier/Power

F 700/800 and 900

D VHF

E UHF

R 700/800 and VHF

T VHF and UHF

E UHF1 and UHF2

S 700/800 and UHF

1 APX 7000

2 APX 7500 Mid Power

3 APX 7500 High Power

4 APX 6000

5 APX 6500 Mid Power

6 APX 6500 High Power

7 APX Low Tier Portable

8 APX Low Tier Mobile MP/APX 4500 MP/APX 2500 MP

9 APX Lowest Tier Mobile MP/APX 1500 MP

MN005720A01-AB

Chapter 2: Standard Configurations
