ASTRO Digital XTS 5000 Model III 17
General Radio Operation
Antenna
Your radio’s operating frequency is 806 to 870 MHz. For information
regarding available antennas, see page 93.
Attach the Antenna
Remove the Antenna
With the radio turned off, turn the
antenna clockwise to attach it.
With the radio turned off, turn the
antenna counter-clockwise to
remove it.
