ASTRO Digital XTS 5000 Model III 3
General Radio Operation
Physical Features of the XTS 5000 Model III
Radio
Programmable Controls
The radio controls that can be programmed to perform various tasks,
the features that can be assigned to them (by a qualified radio
technician), and the pages where these features can be found are
listed below and in “Programmable Features” on page 4.
No. Feature Page No. Feature Page
1 Antenna
2 On/Off/Volume Control
Knob
3 LED
4 Microphone
5 PTT (Push-to-Talk)
Button
6 Menu Select Buttons
17
21
10
7
7 4-Way Navigation Button
8 Home Button
9 Battery
10 Keypad
11 W@P™ Button
12 Display
13 Speaker
14 Universal Connector
8
8
14
9
8
4
19
15 Side Button 2
16 Side Button 1
17 Top Side (Select) Button
18 3-Position A/B/C Switch
19 Top Button
20 2-Position Concentric
Switch
21 16-Position Select Knob
