3. Plug the cord into an AC outlet and then into
charger.
4. Turn the radio OFF.
Note: If the radio is ON while charging, it will take
longer to fully charge.
5. Insert the radio facing down (with battery
installed) into the charging pocket, making sure
the radio contacts are aligned with the MUC
contacts.
Note:
The battery can be charged by itself using the slot
on the flat surface of the charging pocket.
Charging Status LEDs
On the drop-in charger, the radio charging pocket
has an LED Charger.
On the MUC, each of the 6 charging pockets has
an LED. The LEDs are grouped into pairs to show
which charging pockets are paired. The LED is red
when the battery is charging. It turns to green
once the battery is fully charged.
Note: This Multi Unit Charger allows you to clone
up to 2 radios (2 Source radios and 2 Target
radios). For more details, refer to “Radio
Cloning” Section on page 24.
For part number details, refer to the
“Accessories” Section on page 42.
Charger LED Indicator
Status LED Status Comments
Charging Steady
Red
Indication
The charger is
currently
charging.
Charge
Complete
Steady
Green
Indication
Battery is fully
charged.
Battery
Fault (*)
Blinking
Red
Battery was
faulty when
inserted.
Note: The LED is red when the battery is charging. It
turns to green once the battery is fully charged.
Note: (*) Re-seating the battery pack will likely correct
this issue.
