User's Guide

Identifying Radio Controls
English
10
Radio Parts and Controls
Antenna
1
LED
2
Accessory
Connector
5
Home Button
6
7
4-Way
Navigation
Button
Microphone
4
Top (Orange)
Button*
3
Battery
Latch (at the
bottom)
8
10
Menu Select
Buttons
12
13
Main Display
11
Data Feature
Button
9
Multi-
Function
Knob
(MFK)*
14
Side Button 2*
Side Button 1*
17
Push-to-Talk
(PTT) Button
20
Top Side
(Select)
Button*
Battery
15
16
Top
Lightbar
21
Bluetooth
®
Pairing
Indicator
* These radio controls/buttons are programmable.
