Identifying Radio Controls
English
8
Radio Parts and Controls
Antenna
1
LED
2
Accessory
Connector
4
On/Off/Volume
Control Knob
Battery Latch
9
6
3-Position A/B/C
Switch*
Battery
18
10
16-Position
Select Knob*
15
Top
Display
17
Main
Speaker
5
Side Button 2*
14
Side Button 1*
13
12
Push-to-Talk
(PTT) Button
* These radio controls/buttons are programmable
.
11
Top Side (Select)
Button*
Microphone
16
7
2-Position Concentric
Switch*
Belt Clip
8
Top (Orange)
Button*
3
