User's Guide

18
English
FRONT PANEL FEATURE AND
BUTTON CONFIGURATION MODE
Main Menu
1st Level
Sub-Menu
2nd Level
Sub-Menu
Settings Remarks
CHANNEL PL DSPLY
(PL Display Type)
–
FREQ
CODE
Allows you to select the PL display type either in
frequency or code.
RX PL
(RX TPL/DPL)
CH-001...
CH-016
CSQ CSQ
067.0 … 001 ...
254.1 042
023 … or 043
754 127
TPL 1 TPL 1
TPL 2 TPL 2
TPL 3 TPL 3
Allows you to select the range of Receive PL setting
(CSQ, TPL 67.0 - TPL 254.1, DPL 023 - DPL 754, user
defined TPL 1, user defined TPL 2, & user defined TPL
3) if frequency is selected for PL display type.
or
Allows you to select the range of Receive PL setting
(CSQ, 001 - 127, user defined TPL 1, user defined TPL
2, & user defined TPL 3) if code is selected for PL
display type.
TX PL
(TX TPL/DPL)
CH-001...
CH-016
CSQ CSQ
067.0 … 001 ...
254.1 042
023 … or 043
754 127
TPL 1 TPL 1
TPL 2 TPL 2
TPL 3 TPL 3
Allows you to select the range of Transmit PL setting
(CSQ, TPL 67.0 - TPL 254.1, DPL 023 - DPL 754, user
defined TPL 1, user defined TPL 2, & user defined TPL
3) if frequency is selected for PL display type.
or
Allows you to select the range of Transmit PL setting
(CSQ, 001 - 127, user defined TPL 1, user defined TPL
2, & user defined TPL 3) if code is selected for PL
display type.
SQUELCH
(Squelch Level)
CH-001...
CH-016
NORMAL
TIGHT
NORMAL squelch level allows the radio to receive weak
signals. TIGHT squelch level allows the radio to receive
strong signals and eliminates unwanted noise.
TIME OUT (Time Out
Timer)
–
OFF
010
020
...
590
600
This determines the maximum duration (in seconds) that
the radio can transmit continuously.
