Beacon LKP NALA.book Page 1 Thursday, January 29, 2009 2:31 PM CONTENTS 21 21 23 ii Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Radio Overview . . . . . . . . . . . . . . . . . . . . . . . . . . LED Colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . LCD Display and Icons . . . . . . . . . . . . . . . . . . . . . . Programmable Buttons. . . . . . . . . . . . . . . . . . . .
Beacon LKP NALA.book Page ii Thursday, January 29, 2009 2:31 PM COMPUTER SOFTWARE COPYRIGHTS COMPUTER SOFTWARE COPYRIGHTS The Motorola products described in this manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media.
Beacon LKP NALA.book Page iii Thursday, January 29, 2009 2:31 PM SAFETY PRODUCT SAFETY AND RF EXPOSURE COMPLIANCE ! Caution Before using this product, read the operating instructions for safe usage contained in the Quick Reference Card enclosed with your radio. ATTENTION! This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements.
Beacon LKP NALA.
Beacon LKP NALA.
Beacon LKP NALA.book Page 2 Thursday, January 29, 2009 2:31 PM RADIO OVERVIEW 1. Channel Selector Knob Used to select channels in normal radio operation mode. 2. On/Off and Volume Knob Turn the ON/OFF/Volume Control knob clockwise to turn the radio ON. Turn the ON/OFF/Volume Control knob counterclockwise to turn the radio OFF. Turn this knob clockwise to increase the volume. Turn this knob counterclockwise to decrease the volume. 3.
Beacon LKP NALA.book Page 3 Thursday, January 29, 2009 2:31 PM LED COLORS Green Amber Red State Indication Illuminated Radio is transmitting in normal mode. Radio is transmitting in Scrambling Mode. Normal Blinking Radio is receiving in normal mode. Channel is busy. Radio passed self-test during powering up. Illuminated Monitor activated. Permanent Sticky Monitor activated. Normal Blinking Radio is in active Scan Mode. Radio is receiving in Scrambling Mode.
Beacon LKP NALA.book Page 4 Thursday, January 29, 2009 2:31 PM RADIO OVERVIEW LCD Display and Icons Displays selected channel, programming parameters, status messages and any error or information messages. LCD Indicator English Description Description Function Voice Inversion Scrambling Indicator Illuminates when Scrambling Mode is on. Programming Mode Indicator Illuminates when Programming Mode is on. Keypad Lock Indicator Illuminates when keypad is locked.
Beacon LKP NALA.book Page 5 Thursday, January 29, 2009 2:31 PM Programmable Buttons Button Function Monitor • Side Programmable Button 1 Nuisance Removes unwanted channel(s) temporarily from Channel Delete scan list during Scan. Applicable for Long Press Only. • Side Programmable Button 2 TPL/DPL Enable Enables or disables radio from requiring matching TPL/DPL to unsquelch. • Front Programmable Button 1 Power Level Selects required power level: High or Low.
Beacon LKP NALA.book Page 6 Thursday, January 29, 2009 2:31 PM RADIO OVERVIEW Button Volume Set VOX Function Controls the audio level. A programmable button used to control the audio level. The button emits a continuous tone to indicate the current volume level. To change volume level, turn the volume knob to the desired level while pressing the programmable button. Applicable for Long Press only. Enables or disables VOX feature for the selected channel.
Beacon LKP NALA.book Page 7 Thursday, January 29, 2009 2:31 PM GETTING STARTED To Attach Antenna Attaching and Removing the Antenna 1. Fasten the antenna to the radio by placing the threaded end of the antenna into the Antenna Connector. 2. Rotate the antenna clockwise until tight. To Remove Antenna Threaded End of Antenna 1. Turn the antenna in a counterclockwise direction until it disengages from the radio.
Beacon LKP NALA.book Page 8 Thursday, January 29, 2009 2:31 PM Attaching and Removing the Battery To Attach Battery 1. Fit the battery slots with the grooves on the radio. 2. Slide the battery upwards until a click is heard. Grooves GETTING STARTED To Remove Battery Battery Latch Battery Slots English 8 1. Slide the battery latch away from the radio. 2. Slide the battery downwards. 3. Pull the battery away from the radio.
Beacon LKP NALA.book Page 9 Thursday, January 29, 2009 2:31 PM Attaching and Removing the Belt Clip Release Tab Mounting Grooves To Attach Belt Clip 1. Align mounting rails of the belt clip with the grooves of the radio. 2. Slide the belt clip downwards until it clicks into place. To Remove Belt Clip Safely insert a flat tool between the release tab and the back surface of the radio. 2. Lift the release tab. 3. Slide the belt clip upwards. GETTING STARTED 1.
Beacon LKP NALA.book Page 10 Thursday, January 29, 2009 2:31 PM Charging the Battery 5. Turn the radio OFF before charging the battery. Insert a battery, or a radio with a battery into the charger’s pocket by: aligning the groove on each side of the battery with the corresponding raised rail on each side of the charger pocket OR pressing the battery towards the rear of the pocket OR sliding the battery into the charger pocket, ensuring complete contact between the charger and battery contacts. 6.
Beacon LKP NALA.book Page 11 Thursday, January 29, 2009 2:31 PM LED Color Charging Status Charging Blinking Red Battery Fault Solid Green Charge Complete Blinking Green Trickle Charging Single Green Blink Power On Blinking Yellow Waiting to Charge GETTING STARTED Solid Red Note: To get the maximum use from a new battery, charge it overnight (12 to 16 hours) before using the battery for the first time. The typical time needed to completely charge the discharged battery is estimated within 2.
Beacon LKP NALA.book Page 12 Thursday, January 29, 2009 2:31 PM SCAN Scan allows you to monitor multiple channels and receive calls that are transmitted on them. Two types of scan are supported: Normal Scan and Priority Scan. Normal Scan searches all channels sequentially in the radio’s scan list, whereas Priority Scan allocates 50% of the scanning time to the Priority Channel (the first channel in the designated scan list). Start Ch. 2 Ch. 16 Ch. 15 Ch. 2 Ch. 1 Ch.
Beacon LKP NALA.book Page 13 Thursday, January 29, 2009 2:31 PM VOICE OPERATED TRANSMIT (VOX) VOICE OPERATED TRANSMIT (VOX) VOX needs to be enabled for each channel in Customer Programming Software (CPS) before VOX Accessories can be used with radio. When the VOX headset/microphone is connected, your radio may be used in hands-free operation. To start the VOX feature 1. Connect the VOX headset to the accessory connector of the radio. Make sure the radio is turned OFF before connecting the VOX accessory.
Beacon LKP NALA.book Page 14 Thursday, January 29, 2009 2:31 PM VOICE INVERSION SCRAMBLING Your radio has the Voice Inversion Scrambling feature which gives you an extra layer of privacy. This scrambling function is implemented via a frequency inversion in analog mode. Note: This feature needs to be enabled using Customer VOICE INVERSION SCRAMBLING Programming Software (CPS) before it can be activated.
Beacon LKP NALA.book Page 15 Thursday, January 29, 2009 2:31 PM FRONT PANEL FEATURE AND BUTTON CONFIGURATION MODE Assessing Front Panel Feature and Button Configuration Mode Parameters This mode allows you to change the feature parameters to enhance the use of your radio. To Navigate Note: This mode must be enabled using Customer Programming Press the or to scroll through the parameters for each menu or sub-menu item. Software (CPS) before it can be activated.
Beacon LKP NALA.book Page 16 Thursday, January 29, 2009 2:31 PM 1st Level Sub-Menu 2nd Level Sub-Menu – – AUTO TOGGLE Selecting AUTO causes the backlight to automatically extinguish, if there is no keypress for more than 5 seconds. Pressing the Backlight button again prolongs illumination time. Selecting TOGGLE allows the Backlight button toggle to control the ON/OFF status of the backlight. SAVER (Battery Saver) – OFF NORMAL ENHANCED Helps to extend the battery life.
Beacon LKP NALA.book Page 17 Thursday, January 29, 2009 2:31 PM Main Menu ACCESORY (Accessory) 2nd Level Sub-Menu SPK GAIN (External Speaker Gain) – MIC GAIN (External Microphone Gain) – – – Settings +2 +1 0 -1 -2 +2 +1 0 -1 -2 ON OFF Remarks Allows you to adjust the external speaker loudness when accessories are connected to radio. +2 will set the external speaker gain to maximum level and -2 will set the external speaker gain to minimum level.
Beacon LKP NALA.book Page 18 Thursday, January 29, 2009 2:31 PM 1st Level Sub-Menu Main Menu FRONT PANEL FEATURE AND BUTTON CONFIGURATION MODE CHANNEL English PL DSPLY (PL Display Type) 2nd Level Sub-Menu – Settings FREQ CODE Remarks Allows you to select the PL display type either in frequency or code. RX PL (RX TPL/DPL) CH-001... CH-016 CSQ 067.0 … 254.1 023 … or 754 TPL 1 TPL 2 TPL 3 CSQ 001 ... 042 043 127 TPL 1 TPL 2 TPL 3 Allows you to select the range of Receive PL setting (CSQ, TPL 67.
Beacon LKP NALA.book Page 19 Thursday, January 29, 2009 2:31 PM Main Menu SCAN 1st Level Sub-Menu 2nd Level Sub-Menu Settings Remarks 01-XXX 02-XXX … 15-XXX 16-XXX 001… 016 Allows you to set members of Scan List 1. “XXX” denotes the selected scan list member. “_ _ _” shows that no scan list member is selected. User can use the button or the button to scroll the valid channel list and press PTT to set the selection.
Beacon LKP NALA.book Page 20 Thursday, January 29, 2009 2:31 PM 1st Level Sub-Menu Main Menu SCRMBLIN (Voice Inversion Scrambling) CHANNEL (Scrambling Channel Select) FRONT PANEL FEATURE AND BUTTON CONFIGURATION MODE CODE (Scrambling Code Select) English 20 2nd Level Sub-Menu CH-001 … CH-016 – Settings Remarks ENABLE DISABLE Allows you to enable or disable scrambling for a selected channel. CODE 1 CODE 2 Allows you to set the Scrambling Code between the two codes available.
Beacon LKP NALA.book Page 21 Thursday, January 29, 2009 2:31 PM TPL AND DPL FREQUENCIES AND CODES TPL Frequency Table 1: TPL Frequency Equivalent PL Code Motorola Code 67.0 XZ 001 69.3 WZ 002 71.9 XA 003 74.4 WA 004 77.0 XB 005 79.7 WB 006 82.5 YZ 007 85.4 YA 008 88.5 YB 009 91.5 ZZ 010 94.8 ZA 011 TPL Freq (Hz) TPL Freq (Hz) Equivalent PL Code Motorola Code 97.4 ZB 012 100.0 1Z 013 103.5 1A 014 107.2 1B 015 110.9 2Z 016 114.8 2A 017 118.
Beacon LKP NALA.book Page 22 Thursday, January 29, 2009 2:31 PM TPL AND DPL FREQUENCIES AND Table 1: TPL Frequency TPL Freq (Hz) Equivalent PL Code Motorola Code 186.2 7Z 031 192.8 7A 032 203.5 M1 033 206.5 8Z 034 210.7 M2 035 218.1 M3 036 225.7 M4 037 229.1 9Z 038 233.6* M5 039 241.8 M6 040 250.3 M7 041 254.
Beacon LKP NALA.
Beacon LKP NALA.
Beacon LKP NALA.book Page 25 Thursday, January 29, 2009 2:31 PM Table 2: DPL Codes Motorola Code 631 114 632 115 645(*) 116 654 117 662 118 664 119 703 120 712 121 723 122 731 123 732 124 734 125 743 126 754 127 TPL AND DPL FREQUENCIES AND Note: DPL Code The codes marked with an asterisk (*) are not part of the 83 standard EIA/TIA-603 codes.
Beacon LKP NALA.book Page 26 Thursday, January 29, 2009 2:31 PM WARRANTY Products and Accessories Products Covered Length of Coverage CP185 Two-Way Radio Two (2) years from the date of purchase by the first consumer purchaser of the product unless otherwise provided for below. Motorola/Mag One Accessories One (1) year from the date of purchase by the first consumer purchaser of the product.
Beacon LKP NALA.book Page 27 Thursday, January 29, 2009 2:31 PM MOTOROLA, at its option, will at no charge either repair or replace this Product during the warranty period provided it is returned in accordance with the terms of this warranty to the place of purchase. Repair, at MOTOROLA's option, may include the replacement of parts or boards with functionally equivalent reconditioned or new parts or boards. Replaced parts or boards are warranted for the balance of the original applicable warranty period.
Beacon LKP NALA.book Page 28 Thursday, January 29, 2009 2:31 PM WARRANTY WHAT THIS WARRANTY DOES NOT COVER English A) Defects or damage resulting from use of the Product in other than its normal and customary manner. B) Defects or damage from misuse, accident, water, or neglect. C) Defects or damage from improper testing, operation, maintenance, installation, alteration, modification, or adjustment. D) Breakage or damage to antennas unless caused directly by defects in material workmanship.
Beacon LKP NALA.book Page 29 Thursday, January 29, 2009 2:31 PM Exclusions Software Embodied in Physical Media. No warranty is made that the software will meet your requirements or will work in combination with any hardware or software applications provided by third parties, that the operation of the software products will be uninterrupted or error free, or that all defects in the software products will be corrected. Software NOT Embodied in Physical Media.
Beacon LKP NALA.book Page 30 Thursday, January 29, 2009 2:31 PM ACCESSORIES BATTERIES The following accessories parts are compatible with model number CP185. ANTENNAS Motorola Part Number Description VHF Heliflex Antenna, 146 – 174 Mhz PMAD4049_ VHF Helical Antenna, 146 – 174 MHz NAE6483_R UHF Whip Antenna, 403 – 520 MHz (16.
Beacon LKP NALA.
Beacon LKP NALA.
Beacon LKP NALA.
Beacon LKP NALA.book Page 36 Thursday, January 29, 2009 2:31 PM MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. © 2008 by Motorola, Inc. All rights reserved.
