User's Manual

APPLICANT: MOTOROLA EQUIPMENT TYPE: ABZ89FC5812
User / Operational Manual
Functional Description / Operation of Modules and Interconnect (Draft)
EXHIBIT D1-6
Pin # Signal Type Function/Notes
14 GND
15 NC
16 GND
17 PWR_ON_
SEQUENCE
Input Provides 2V (Host Core) power up
sequence control
18 GND
19 NC
20 GND
21 ETH_TX2+ Output Redundant Ethernet Link
22 GND
23 ETH_TX2- Output Redundant Ethernet Link
24 GND
25 NC
26 GND
27 12VDC
28 12VDC
29 12VDC
30 12VDC
31 NC
32 GND
33 ETH_RX2+ Output Redundant Ethernet Link
34 GND
35 ETH_RX2- Output Redundant Ethernet Link
36 GND
37 NC
38 SPARE
39 TDM_TX1+ Input Primary TDM Link
40 GND
41 TDM_TX1- Input Primary TDM Link
42 GND
43 NC
44 SPARE
45 TDM_CLK1+ Input Primary TDM Link
46 GND
47 TDM_CLK1- Input Primary TDM Link
48 GND
49 NC
50 SPARE
51 TDM_TX2+ Input Redundant TDM Link
52 GND
53 TDM_TX2- Input Redundant TDM Link
54 GND
55 NC
56 SPARE
57 TDM_CLK2+ Input Redundant TDM Link
58 GND
59 TDM_CLK2- Input Redundant TDM Link
60 GND
61 3.3VDC
62 3.3VDC
63 3.3VDC
64 3.3VDC
65 3.3VDC
66 3.3VDC
67 3.3VDC
68 3.3VDC
69 Wattmeter_Vf Input Wattmeter Forward Power voltage
70 GND
71 NC
72 GND
