User's Manual

APPLICANT: MOTOROLA EQUIPMENT TYPE: ABZ89FC5812
User / Operational Manual
Functional Description / Operation of Modules and Interconnect (Draft)
EXHIBIT D1-6
Pin # Signal Type Function/Notes
18 Aux Out2 Output Customer-defined transistor buffered output
19 Aux Out3 Output Customer-defined transistor buffered output
20 Aux Out4 Output Customer-defined transistor buffered output
21 Aux Out5 Output Customer-defined transistor buffered output
22 Aux Out6 Output Customer-defined transistor buffered output
23 Aux Out Relay7
N.O.(RdStat)
N.O. contact of Relay A (Note1)
24 Aux Out Relay7 Com
(RdStat)
COM contact of Relay A (Note1)
25 Aux Out Relay8 N.O. N.O. contact of Relay A
26 Aux Out Relay8 Com COM contact of Relay A
27 Aux Out Relay9 N.O. N.O. contact of Relay A
28 Aux Out Relay9 Com COM contact of Relay A
29 Aux Out Relay10 N.O. N.O. contact of Relay A
30 Aux Out Relay10 Com COM contact of Relay A
31 GND
32 Aux Out11 Output Customer-defined transistor buffered output
33 Ext_Reset Input External Reset Input (to CPLD)
34 GND
35 GND
36 Mute Monitor In Input 6809 Mute / MRTI Monitor Input
37 CCI / PL Strip In Input 6809 CCI / MRTI PL Strip Input
38 RxAudio Output 6809/MRTI RX Audio output
39 RSTAT/Aux Indicate Out
Detect
Output 6809 RSTAT / MRTI Aux Indicate output
40 TSTAT/RXCarrier Detect Output 6809 TDATA / MRTI RX Carrier output
41 Tx Data+ Input 6809 Tdata to AuxTX ADC
42 TX Data -/GND Ground
43 MRTI TxAudio In Input MRTI Transmit Audio (to PCM Codec)
44 Patch Inhibit Out Output MRTI Patch Inhibit output
45 GND
46 GND
47 PL+ Input
48 PL- Input
49 Gen TX+ Input
50 GenTX- Input
Transceiver Power / Backplane Connector
This connector provides the interconnect between the XCVR Control and XCVR RF (Exciter and Receiver) board
which also incorporates the power supply. This connector consists of the two 10/100 BaseT Ethernet signals, SPI
signals for the 28.6 VDC power supply and Power Amplifier, Fan Kit signals, and the CP2 TDM links. All of these
signals go to the backplane. This connector also supplies the XCVR Control board with power from the power
supply on the XCVR RF board.
XCVR Power/Backplane Interconnect
Pin # Signal Type Function/Notes
1 ETH_TX1+ Output Primary Ethernet Link
2 GND
3 ETH_TX1- Output Primary Ethernet Link
4 GND
5 NC
6 SPARE
7 ETH_RX1+ Input Primary Ethernet Link
8 GND
9 ETH_RX1- Input Primary Ethernet Link
10 GND
11 NC
12 GND
13 SPARE
