V.24 Port
This port can be used for either synchronous or asynchronous applications. This RJ45 connector and pinout is
the same as used on previous product V.24 boards. This port can also be configured for asyncronous operation.
This port interfaces to SCC1 of the MPC8250.
Synchronous V.24 RJ-45 Telco Pin-out (on Xcvr)
RJ-45 Pin
#
V.24
Signal
Type Resource
1 RCLK Input PC20
2 RX Line Det. Input PC14
3 TCLK Input/Output PC29
4 GND GND
5 RX Data Input PD31
6 TX Data Output PD30
7 CTS Input PC15
8 RTS Output PD29
External 1 PPS
The external 1PPS connector currently resides on the Backplane. It is DC coupled, high impedance input,
accepts 3.3V DC TTL level signals and is 5 Volt tolerant.
External References
There are two external references (Ext_Ref and 5MHz_In). The Ext_Ref signal resides on the Backplane. It
accepts both 5 MHz, 5 MHz / 1 PPS, and 10 MHz references and is DC coupled. The second external reference
(5MHz_In) is located on the front panel behind the fan assembly. It has a 50 ohm input resistance and is AC
coupled. This input will be used to align the OCXO residing on the SAC.
System Connector
The System connector is a 50-pin Mini SCSI connector. It is used for all the Wildcard general purpose inputs and
outputs. It also provides I/O for both MRTI Phone Patch and 6809 Trunking Controller configurations.
Wildcard Connector
Pin # Signal Type Function/Notes
1 Aux In1 (Site Failsoft) Input Customer-defined transistor buffered input (Note1)
2 Aux In2 (TX Inhibit) Input Customer-defined transistor buffered input (Note1)
3 Aux In3 (Rx Inhibit) Input Customer-defined transistor buffered input (Note1)
4 Aux In4 (Duplex Enable) Input Customer-defined transistor buffered input (Note1)
5 Aux In5 (In Cabinet
Repeat)
Input Customer-defined transistor buffered input (Note1)
6 Aux In6 Input Customer-defined transistor buffered input
7 Aux In7 Input Customer-defined transistor buffered input
8 Aux In8 Input Customer-defined transistor buffered input
9 Aux In 9 Opto+
(Ext_PTT)
Aux In 9
Opto+
(Ext_PTT)
Opto-isolated customer defined input (Opto A+)
10 Aux In 9 Opto-
(Ext_PTT)
Aux In 9
Opto-
(Ext_PTT)
Opto-isolated customer defined input (Opto A-)
Doubles as MRTI PTT and 6809 PTT
11 Aux In 10 Opto+ Input Opto-isolated customer defined input
12 Aux In 10 Opto- Input Opto-isolated customer defined input
13 Aux In 11 Opto+ Input Opto-isolated customer defined input
14 Aux In 11 Opto- Input Opto-isolated customer defined input
15 Aux In 12 Opto+ Input Opto-isolated customer defined input
16 Aux In 12 Opto- Input Opto-isolated customer defined input
17 Aux Out1 (Failsoft
Indicate)
Output Customer-defined transistor buffered output (Note1)
