Installation Guide

83TriStar MPPT 600V Operator’s Manual
82
Appendix
OVER-VOLTAGE RANGE
Vb = 40 V
Vb = 50 V
15A INPUT CURRENT LIMIT
60 Amp Battery Current Limit
60 Amp Battery Current Limit
Vb = 30 V
60 Amp Battery Current Limit
Vb = 20 V
60 Amp Battery Current Limit
60 Amp Battery Current Limit
Vb = 60 V
0
100 200 300 400 500 600
500
1000
1500
2000
2500
3000
3500
INPUT VOLTAGE (Volts)
POWER (Watts)
Output Power vs. Array Input Voltage
Figure 10-3. Output Power vs. Array Voltage
0
10
20
30
40
50
60
70
60 65 70 75 80 85 90 95
Heatsink Temperature (degrees C)
Battery Current (Amps)
Battery Current vs. Heatsink Temperature
Figure 10-2. Battery Current vs. Heatsink Temperature
