Networking and Communication
Serial Port Settings
Adjust the serial port settings as follows:
• 9600 BAUD
• 8 data bits
• 1 or 2 stop bits
• no parity
The serial RS-232 connection provides a direct connection between a TriStar MPPT 600V and a
PC (or other serial device). Firmware updates can only be programmed through the RS-232
connection. The serial connection is not typically used for multi-controller networking. However,
networking is possible using a USB hub and USB-Serial cables. For more information, refer to
the “Morningstar Communications Document” on our website at: http://www.morningstarcorp.com
5.4 EIA-485 (formerly RS-485)
NOTE:
The RS-232 and EIA-485 ports share hardware. Both ports cannot be used simultaneously.
EIA-485 is a networking standard for serial communication between multiple devices on a bus.
The TriStar MPPT 600V communicates over an EIA-485 network via the open standard MOD-
BUS
TM
protocol. Use EIA-485 networking to:
• connect multiple TriStar MPPT 600V controllers on a network to log and view real-time
data using MSView
TM
PC software
• program each controller on the network with custom charge settings using MSView
TM
PC
software
• connect the TriStar MPPT 600V to other Morningstar controllers with the RSC-1 Serial to
EIA-485 Adapter (sold separately)
• bridge an Ethernet connection through a TriStar MPPT 600V to an EIA-485 network
The EIA-485 port has four (4) connections: Power, Data A, Data B, and Ground. Data A & B are
differentially driven data lines that carry the network data. Power and Ground connections pro-
vide power to the network. The TriStar MPPT 600V does not supply power to the EIA-485 net-
work, therefore an external power source is required. The source voltage must be between 8-16
Vdc.
!
CAUTION: Equipment Damage
Tapping power off of individual batteries in a series string of batteries can cause a voltage imbalance.
Damage to the batteries may result. Always use a DC-DC converter to power the EIA-485 network.
!
PRUDENCE : Endommagement de l’équipement
L’arrêt progressif de batteries individuelles dans une série de batteries peut provoquer un déséquilibre
de tension. Les batteries peuvent être endommagées. Utilisez toujours un convertisseur CC-CC pour
convertir l’alimentation au réseau EIA-485 si la tension nominale du système est supérieure à 12 V.
For more information on EIA-485 networking, refer to the “Morningstar Communications Docu-
ment” on our website at: http://www.morningstarcorp.com
