M40DV-PFC Peninsula Gas Fireplace
Introduction
The M40DV-PFC is a direct-vented, 3-sided Gas Fireplace with an
adjustable burner. It can be converted to both a top vent or rear vent
unit, and it is available in two models:
n Model M40DV-PFC (continuous pilot)
n Model M40DV-PFC-I (intermittent pilot)
n Model M40DV-PFC-MH (mobile home)
For Mobile Home Approved Models See Appendix B
This manual covers both models and unless otherwise specified, the
designation M40DV-PFC refers to both models. Sections which are
specific to a particular model are marked with a symbol,
plus the appropriate model number.
The M40DV-PFC is rated for:
n Natural Gas at 30,000 BTU/H (8.79 Kilowatts) max. input,
and 24,000 BTU/H (7.03 Kilowatts) min. input.
n Propane at 30,000 BTU/H (8.79 Kilowatts) max. input, and
24,000 BTU/H (7.03 Kilowatts) min. input.
The Montigo warranty will be voided by, and Montigo disclaims any
responsibility for, the following actions:
n Modification of the fireplace and/or components including Direct-
Vent assembly or glass doors.
n Use of any component part not manufactured or approved by
Montigo in combination with this Montigo fireplace system.
n Installation other than as instructed in this manual.
Consult your local Gas Inspection Branch on installation requirements
for factory-built gas fireplaces. Installation & repairs should be done by
a qualified contractor.
Installations in Canada must conform to the current CAN/CGA B-
149.1 and .2 Gas Installation Code and local regulations. This
fireplace's fans must be electrically grounded in accordance with CSA
C22.1 Canadian Electrical Code Part 1 and/or Local Codes.
Installations in the USA must conform to local codes, or in the
absense of local codes to the National Fuel Gas Code, ANSI Z223.1-
1988. The fans must be grounded in accordance with local codes or, in
the absence of local codes, with the National Electrical Code, ANSI/
NFPA 70-1987.
Table Of Contents
Introduction............................................................................. 2
Installation ........................................................................3 - 14
Installing the Fireplace Shell........................................... 3
Installing the Gasline ...................................................... 4
The Remote Switch ....................................................... 4
Direct Vent Installation ................................................... 4
Terminations ..................................................... 5
Converting to Top Vent or Rear Vent model
(Installing the Flue cover) .................................. 6
Rear Vent Venting Requirements ...................... 6
Rear Vent Horizontal Venting Runs ................... 7
Rear Vent Vertical Venting Runs ....................... 8
Top Vent Venting Requirements........................ 9
Top Vent Horizontal Venting Runs................... 10
Top Vent Vertical Venting Runs ....................... 11
Reduced Vertical Venting ................................ 12
Construction around the fireplace
Facing ........................................................... 12
Mantels and Surrounds ................................... 12
Wiring ........................................................... 13
Removing and Installing the Door ................................ 13
Installing the Logset ..................................................... 14
Installing the Ember Material ........................................ 14
Operation ..........................................................................14-16
Model M40DV-PFC ..................................................... 15
Model M40DV-PFC-I ................................................... 16
Maintenance ..................................................................... 17-18
Warranty ................................................................................. 19
Appendix
A. Termination Locations ............................................. 20
B. Mobile Home Approved Models ............................... 21
CAUTIONS
Due to its high operating temperatures, the appliance
should be located out of traffic & away from furniture and
draperies.
• Children and adults should be alerted to the hazards
of the high surface temperature, which could cause
burns or clothing ignition.
• Young children should be carefully supervised when
they are in the same room as the appliance.
• Clothing or other flammable materials should not be
placed on or near the appliance.
