Replacement Part List

Model Number 8KGR72BKD

Date issued 9/2018 Rev. #0

Fan Model Number: (Printed on your product packaging) 8KGR72BKD

NUMÉRO DE MODÈLE DU VENTILATEUR: (IMPRIMÉ SUR L’EMBALLAGE DE VOTRE PRODUIT) 8KGR72BKD

PACKAGE CONTENTS- YOUR FAN BOX CONTAINS THE FOLLOWINGS:

CONTENU– LA BOÎTE DE VOTRE VENTILATEUR CONTIENT LES ÉLÉMENTS SUIVANTS:

PARTS THAT COULD BE ORDERED FOR REPLACEMENT

PIÈCES DE REMPLACEMENT QUI PEUVENT ÊTRE COMMANDÉES

Glass Broken? Missing Parts? Need Help?

Verre brisé? Pièces manquantes? Besoin d’aide?

Call our customer service center, Monday - Friday from 8:00 a.m. - 6:30 p.m. EST at 1-800-969-3347

Appeler notre centre de service au consommateur, ouvert de lundi - vendredi de 8 h à 18 h 30 HNE (heure

normale de l’Est) à 1-800-969-3347

PART DESCRIPTION QUANTITY

A Mounting bracket 1

B Canopy 1

C Canopy ring 1

D Downrod 1

E Yoke cover 1

F Motor assembly 1

G Blade 8

H Blade support kit 8

I Light plate 1

J LED light fixture 1

K Glass 1

L Receiver 1

M Transmitter 1

N Hardware pack 1

Ref# Part # Description

1 131-1141 Blade/Sets, Dark Walnut, ABS, Kingston, BK

2 200-141 LED light fixture, DOB 18W, Kingston series

3 G-1119 Glass, Opal Etched, Kingston series

4 101-365 Mounting Hardware Kit BK, Kingston, BK

5 100-295 Receiver, 6 speed, Kingston series

6 100-238 Transmitter, 6 speed, Kingston series

7 127-614 Downrod,BK, 6", Zinc alloy ball, Kingston BK

8 102-1184 Hardware pack,Kingston BK

PAGE 1
Model Number 8KGR72BKD Date issued 9/2018 Rev.
PAGE 2
Operation & Maintenance Operation Turn on the power and check operation of fan. Speed settings for warm or cool weather depend on factors such as room size, ceiling height and number of fans. Warm weather - (Forward) Fan turns in a counterclockwise direction. A downward air flow creates a cooling effect as shown in Illustration A. This allows you to set your air conditioner on higher temperature settings without affecting your comfort. Cool weather - (Reverse) Fan turns in a clockwise direction.
