Installation Guide

Install 4 x 25 watt incandescent can-
delabra bulbs.
Use 3 thumb screws to attach upper
glass to holder.
Install upper glass and holder to fan
body.
Remove 3 screws on arch hub.
Loosen lock nuts and screws on yoke
till you can not feel screws on inside
of yoke.
10
15
12
13
Use 3 screws removed to attach arch
brackets to arch hub.
11
14
Loosen 2 screws and remove gate.
Save gate for use later.
9
Lift mounting neck to mounting Plate
and align screws.
7
S
ecure mounting neck to the mount-
ing plate with four screws to become
a complete mounting bracket.
8
Slide canopy, ball, arch assembly,
and yoke cover over downrod.
Thread lead wires and safet
y cable
through downrod as shown.
Remove keeper from cross pin and then
cross pin from yoke. Replace keeper on
cross pin and save.
Align hole in downrod with hole in
yoke and install cross pin. Install
downrod assembly into y
ok
e. Install
keeper into cross pin.
