Owner’s Manual Ceiling Fan Installation Instructions Total fan weight with light kit included For 5SBR56 Series Fans READ AND SAVE THESE INSTRUCTIONS Quality Ceiling fans
Installation SAFETY TIPS WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 701999), including fire-rated construction. Use this unit only in the manner intended by the manufacurer. If you have any questions contact the manufacturer.
7 8 9 Lift mounting neck to mounting Plate and align screws. Secure mounting neck to the mounting plate with four screws to become a complete mounting bracket. Loosen 2 screws and remove gate. Save gate for use later. 10 11 12 Remove 3 screws on arch hub. Use 3 screws removed to attach arch brackets to arch hub. Use 3 thumb screws to attach upper glass to holder. 13 14 15 Install upper glass and holder to fan body. Install 4 x 25 watt incandescent candelabra bulbs.
19 20 21 Safety cable installation Safety Cable Lag Screw safety cable washer 3” lag screw Tighten 2 downrod set screws and lock nuts. Hang assembled fan from the mounting bracket installed to ceiling in previous step. Make sure the fan is hanging straight. Rotate fan until the tab on the Mounting bracket engages the slot on the Downrod Ball. This must be done to prevent the fan body from rotating when the blades are in motion.
31 32 33 Plug white wire from fan to white wire from light kit. Then plug black wire from fan to black wire from light kit. Lift light kit to the fan motor assembly. Align the 3 screws with the key hole slot holes in the light kit (see inset). Rotate the light kit as shown. Then install the screw removed in the previous step though the closed hole. Tighten all 3 screws securely. Install the 2x50 watt halogen bulbs. Do not touch bulb surface as oily residue from skin can cause the bulb to explode.
Remote Control Transmitter Features: LED LIGHT MEDIUM SPEED LOW SPEED FAN OFF SETTING (Turns fan off only) FAN REVERSE (Press once to change direction of the fan)Fanmust be running to reverse. HIGH SPEED UPLIGHT ON/OFF SETTING AND DIMMER (Press and hold to dim light infinitively) DOWNLIGHT ON/OFF SETTING AND DIMMER (Press and hold to dim light infinitively) FAN SPEED Depress “l dot” for low speed, “2 dots” for medium or “3 dots” for high. To turn fan off press square”.
Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet.
