Replacement Part List

Model Number 3CLYR42RZWD

Date issued 11/2013 Rev. #0

Fan Model Number: (Printed on your product packaging) 3CLYR42RZWD

NUMÉRO DE MODÈLE DU VENTILATEUR: (IMPRIMÉ SUR L’EMBALLAGE DE VOTRE PRODUIT) 3CLYR42RZWD

PACKAGE CONTENTS- YOUR FAN BOX CONTAINS THE FOLLOWINGS:

CONTENU– LA BOÎTE DE VOTRE VENTILATEUR CONTIENT LES ÉLÉMENTS SUIVANTS:

PARTS THAT COULD BE ORDERED FOR REPLACEMENT

PIÈCES DE REMPLACEMENT QUI PEUVENT ÊTRE COMMANDÉES

Glass Broken? Missing Parts? Need Help?

Verre brisé? Pièces manquantes? Besoin d’aide?

Call our customer service center, Monday - Friday from 8:00 a.m. - 6:30 p.m. EST at 1-800-969-3347

Appeler notre centre de service au consommateur, ouvert de lundi - vendredi de 8 h à 18 h 30 HNE (heure

normale de l’Est) à 1-800-969-3347

Driver preassembled

PART DESCRIPTION QUANTITY

A Mounting plate 1

B Motor assembly 1

C Housing 1

D Blade 3

E Light pan 1

F Light kit 1

G Remote receiver 1

H Remote transmitter 1

Hardware pack

Preassembled in fan

Parts # Description

1 131-944 Blade/Set, ABS, RZW

2 133-643

Light kit, RZW, LED 17W, (Driver Preassembled)

3 101-202 Mounting Hardware Kit, Bright Zinc Plating

PAGE 1
Model Number 3CLYR42RZWD Date issued 11/2013 Rev. #0 PARTS THAT COULD BE ORDERED FOR REPLACEMENT PIÈCES DE REMPLACEMENT QUI PEUVENT ÊTRE COMMANDÉES Ref# Parts # 1 2 3 Description 131-944 133-643 101-202 Blade/Set, ABS, RZW Light kit, RZW, LED 17W, (Driver Preassembled) 1 Mounting Hardware Kit, Bright Zinc Plating 3 2 Driver preassembled Glass Broken? Missing Parts? Need Help? Verre brisé? Pièces manquantes? Besoin d’aide? Call our customer service center, Monday - Friday from 8:00 a.m.
PAGE 2
Operation & Maintenance Operation Turn on the power and check operation of fan. Speed settings for warm or cool weather depend on factors such as room size, ceiling height and number of fans. Warm weather - (Forward) Fan turns in a counterclockwise direction. A downward air flow creates a cooling effect as shown in Illustration A. This allows you to set your air conditioner on higher temperature settings without affecting your comfort. Cool weather - (Reverse) Fan turns in a clockwise direction.
