Instructions / Assembly

2 WAYS TO ATTACH TO PLAYSET
GROMMETS AND TRIM VARIANCE
OPTION 2:
OUTSIDE MOUNT
OPTION 1:
WRAP AROUND
INSIDE MOUNT
Purchase washer screws
to attach through grommets
Purchase washer screws
to attach through grommets
MEASURING INSIDE MOUNT
Place tape measure on the inside of wood beam you
want to attach the tarp to. Measure around that beam,
over the play set peak and down and around the other
beam to the edge of the wood.
MEASURING OUTSIDE MOUNT
Place tape measure on the edge of the
outside beam. Measure over the peak and to
the other outside beam edge.
Some palysets will allow you to wrap the canopy around the beam for an inside mount (option 1). Others will have spindles or obstructions that will
not allow the tarp to wrap around for an inside mount, so the tarp would mount to the outside of the beam (option 2).
There is a total trim variance of 1”. Meaning the tarp may trim anywhere from the exact size you order to 1“ shorter.
Unfortunately trimming and sewing tarps is not an exact process. We try our best to trim and hem to your exact
dimensions, but The tarp may trim anywhere from the exact ordered size to 1” shorter than your ordered size. Please take
that into consideration when ordering .
Grommets are placed 1/4“ to 1/2” from the trim edge. So if measuring from the screw holes from your previous, please
make sure you add on .5 to 1” to accomodate the grommet distance.
Use washer screws to attached through grommets (washer screws are not inncluded, but can be found at any hardware
store)
Grommet Placement: 1/4”” to 1/2” from the trim edge
Grommet Dimesions: 3/4“ outer diameter with a 3/8” hole
Grommets placed every 1-2 feet
grommet diameter
IMPORTANT TRIM VARIANCE: There is a total trim variance of 1”.
Meaning the nal tarp size may be anywhere from the exact size you order to 1“ shorter.
