Datasheet

This document was generated on 09/14/2019
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
0734120231
Status:
Active
Overview: RF/Microwave Products
Description: MCRF-to-MCRF, 1.13mm Cable Diameter, Length 110.00mm, 50 Ohms
Documents:
Drawing (PDF) RoHS Certificate of Compliance (PDF)
General
Product Family Cable Assemblies
Series 73419
Assembly Configuration Dual Ended Connectors
Connector to Connector MCRF-to-MCRF
Overview RF/Microwave Products
Product Name MCRF, RF
UPC 822348215942
Physical
Cable Length 110.00mm
Circuits (Loaded) 0
Gender Plug/Plug
Material - Metal Phosphor Bronze
Material - Plating Mating Gold
Net Weight 0.460/g
Packaging Type Bag
Single Ended No
Wire/Cable Type Coaxial
Electrical
Impedance
50Ω
Solder Process Data
Lead-freeProcess Capability N/A
Material Info
Reference - Drawing Numbers
Sales Drawing SD-73412-023
Series image - Reference only
EU ELV
Not Relevant
EU RoHS China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/71/2019 (16 July
2019)
Halogen-Free
Status
Low-Halogen
For more information, please visit Contact US
China ROHS Green Image
ELV Not Relevant
RoHS Phthalates Not Contained
Search Parts in this Series
73419 Series
