Datasheet

This document was generated on 06/07/2019
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
0015040219
Status:
Active
Overview: KK® Interconnect System - Molex
Description: 3.96mm Pitch KK Polarizing Key without Boss
Documents:
3D Model RoHS Certificate of Compliance (PDF)
Drawing (PDF)
General
Product Family Accessories
Series 2560
Component Type Polarizing Key
Overview KK® Interconnect System - Molex
Product Name KK
UPC 800753605404
Physical
Circuits (Loaded) 1
Circuits (maximum) 1
Color - Resin Natural
Lock to Mating Part No
Material - Resin Nylon
Net Weight 0.037/g
Packaging Type Bag
Solder Process Data
Lead-freeProcess Capability N/A
Material Info
Engineering Number 2560-1
Reference - Drawing Numbers
Sales Drawing SD-2560
Series image - Reference only
EU ELV
Not Relevant
EU RoHS China RoHS
Compliant
REACH SVHC
Not Contained Per
-ED/88/2018 (15
January 2019)
Halogen-Free
Status
Low-Halogen
For more information, please visit Contact US
China ROHS Green Image
ELV Not Relevant
RoHS Phthalates Not Contained
Search Parts in this Series
2560 Series
Use With
2139 KK Crimp Terminal. 2145 KK PC
Board Connector
