Specification

29/32"
(23mm)
2-31/32"
(75mm)
Wynford™ Accessories Technical Specication
Tank Lever
YB5201
Stock Numbers:
Dimensions:
Installation Instructions:
Directions below are for installation into drywall. If installing product into
a stud,use the wood screws only.
1. Using ¼” drill bit, drill one pilot hole for post.
2. Position mounting post to wall by inserting wall anchor into pilot
 holeandpressingrmly.
3. Make sure that locking tab on mounting post is facing down.
4. Tightenwallanchorscrewwhileholdingmountingpostrmlyinplace.
Tighten anchor until resistance increases. DO NOT over tighten.
5. Using tip of screw bit press wall spikes (metal pieces on outer edge
of mounting post) into drywall.
6. Attachpostbypressingrmlytomountingpostuntilitclicks.
(The square opening at the base of the post must be facing down to
match-up with locking tab).
Cleaning Instructions:
Stock Number:
By MOEN
Tank Lever
25300 AL MOEN DRIVE • NORTH OLMSTED, OH 44070
CORPORATE HEADQUARTERS: [phone] • FAX: [phone]
INTERNATIONAL: [phone] • FAX: [phone]
CUSTOMER SERVICE (USA): [phone] • FAX: [phone]
WWW.MOEN.COM ©Copyright Moen, Inc.
Tank Lever post is constructed of zinc.
Materials:
Materials:
☐
YB5201CH - Tank Lever
Chrome Finish
☐
YB5201BN - Tank Lever
Brushed Nickel Finish
☐
YB5201NL - Tank Lever
Polished Nickel Finish
☐
YB5201ORB - Tank Lever
Oil Rubbed Bronze Finish
Topreservethenenishofthisproduct,cleanonlywithasoft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
1-7/8"
(47mm)
2-1/8"
(54mm)
