Instructions / Assembly

19
6-583.11
MOUNTING
BRACKET
SIZE 30-75
REAR VIEW
ACCESS VIEW
ELECTRICAL
CONNECTION
POWER VENTER
VENT PIPE
CONNECTION
GAS
CONNECTION
ADJUSTABLE
LOUVERS
14.9" BETWEEN 3/8"-16 MOUNTING HOLES
(MODEL SIZES 100 AND 125 ONLY)
MOUNTING HOLES TYP
3/8 x 1" LONG
13.5" BETWEEN 3/8"-16 MOUNTING HOLES
(MODEL SIZES 100 AND 125 ONLY)
ACCESS
PANEL
H
B
1.00
A
F
J
I
D OPENING
C
3.5"
G
E
OPENING
10"
Mounting brackets are slotted to accomodate
joists on 16" or 24" centerlines.
HD/HDB
100/125
(Accessory)
HD/HDB
30-75
.00
1.50
3.50
5.50 7.50
9.50
25.50
27.50 29.50
31.50
33.50 35.00
26.20
25.10 23.10
21.10 19.10 17.10
9.10
7.10
5.10 3.10 1.10
.00
Propeller Units - Model HD
Figure 19.1 - Dimensional Drawings - Model HD
Figure 19.2 - Dimensional Drawings - Model HDB
Blower Units - Model HDB
Table 19.1 - Dimensions (inches) - HD
Table 19.3 - Clearance to Combustibles, Model HD/HDB Figure 19.3 - Mounting
REAR VIEW
ACCESS VIEW
GAS
CONNECTION
ELECTRICAL
CONNECTIONS
ACCESS
PANEL
B
1.0"
D OPENING
H
F
MOUNTING
BRACKETS
SIZE 30-75
POWER VENTER
VENT PIPE
CONNECTION
A
I
J
C
E
OPENING
ADJUSTABLE
LOUVERS
MOUNTING HOLES TYP
3/8 X 1" LONG
G
14.9" BETWEEN 3/8"-16 MOUNTING HOLES
(MODEL SIZES 100 AND 125 ONLY)
14.9" BETWEEN 3/8"-16 MOUNTING HOLES
(MODEL SIZES 100 AND 125 ONLY)
3.5"
10.0"
Table 19.2 - Dimensions (inches) - HDB
HD30 HD45 HD60 HD75 HD100/125
26.8 26.8 26.8 26.8 35.5
12.2 12.2 18.0 18.0 20.5
16.5 16.5 16.5 16.5 22.0
14.9 14.9 14.9 14.9 22.5
10.1 10.1 15.9 15.9 18.4
7.5 7.5 10.7 10.7 14.0
18.5 18.5 18.5 18.5 -
7.6 7.6 7.8 7.8 8.4
1/2 1/2 1/2 1/2 1/2
34.5 34.5 34.5 34.5 43.0
22 22 25 25 31.0
10 10 14 14 18.0
55 60 80 85 125
3 3 3 3 4
Models
A
B
C
D
E
F
G
H
Gas Connection
I
J
Fan Diameter
Approx. Shipping Weight (lbs.)
Vent Connector Size (in)
HDB60 HDB75 HDB100/125
26.8 26.8 35.5
18.0 18.0 20.5
16.5 16.5 22.0
14.9 14.9 22.5
15.9 15.9 18.4
10.7 10.7 14.0
18.5 18.5 -
7.8 7.8 8.4
1/2 1/2 1/2
34.5 34.5 44.5
25.0 25.0 41.5
9 - 7 9 - 7 10 - 10
92 97 151
3 3 4
Models
A
B
C
D
E
F
G
H
Gas Connection
I
J
Blower
Approx.Shipping Weight (lbs.)
Vent Connector Size (in)
DIMENSIONAL DATA - MODEL HD/HDB
Recommended Service
Clearance
HD HDB HD/HDB
Top and Boom 1" 6" 18"
Access Side 1" 6" 18"
Non-Access Side 1" 6" 18"
Rear 18" 18" 18"
Vent Connecto
r
4" 4" 18"
Clearance to Combusble
MaterialUnit Side
