AS-MLV-P2 − Electrical Characteristics
The sensor elements operate at an elevated temperature. The
elevated temperature is realized by means of the Pt heater
which is implemented within the silicon nitride membrane. The
recommended operating temperature for the AS-MLV-P2 is
300°C, which is equivalent to an applied power of approx.
34mW at room temperature.
Figure 5:
Electrical Characteristics
Note(s):
1. This lifetime can only be reached with respect to the recommended operation of the sensor. Especially the maximum ratings during
operation have to be followed carefully. With this background, the AS-MLV-P2 is maintenance free and shall require no replacement
during specified lifetime.
2. Pt heater element operates at 300°C
Description Value
Resistance Values
Sensor resistance range 3kΩ to 3MΩ
Typical baseline in ambient air 50kΩ to 500kΩ
Heater resistance
(2)
150Ω ± 30Ω at 300°C
Absolute Maximum Supply Ratings
Power supply 50mW (very short time range)
Heater current 25mA
Heater Voltage 3.0 V
Lifetime Requirements
Expected lifetime
(1)
10 years
With a minimum of 85.000 hours
On/off cycles 20.000 times
Sensor Element Response
Response from 10%
To its final value 90%
For 0 - 20 ppm CO within < 10sec
Sensor Element Recovery
Response from 10%
To its final value 90%
Back from 20 – 0 ppm CO < 1min
Electrical Characteristics
